Oil cooler E065-411-4

Oil cooler - E065-411-4  - MOTA
Oil cooler - E065-411-4  - MOTA
Add to favorites
Compare this product


Characteristics

Material
oil
Maximum temperature

Max.: 120 °C
(248 °F)

Min.: 90 °C
(194 °F)

Flow rate

Max.: 30.6 l/min
(8.084 us gal/min)

Min.: 8 l/min
(2.113 us gal/min)

Pressure

Max.: 16 bar
(232.06 psi)

Min.: 10 bar
(145.038 psi)

Description

""E"" range Oil cooler with Ø65mm diametre, 411mm length and 4 passes on hot side. Standard version, with copper tubes and brass covers. MORE INFO Our new standard range of oil coolers has been designed to maintain all aspects that made MOTA success, while optimizing all aspects to improve cost:: Reliability: Best features gained from extensive experience (+40 years), such as floating bundle to prevent thermal stress, double o-ring sealing to ensure a complete safety toward fluid-mixing , double leak-test of coolers to guarantee a leak-free cooler Performance: All MOTA know-how in performance design validated by OEM applications, integrated to optimize standard coolerss. Modularity: Only pay for what you need: select the size, features, material and arrangements in available conbinations to match your specific requirements Maintenance: Dismountable coolers for maintenance and available spare parts if necessary
