AC motor induction400 V4/8 poles
Add to favorites
Compare this product
Characteristics
- AC/DC
- AC
- Type
- induction
- Voltage
- 400 V
- Number of poles
- 4/8 poles
- Applications
- for industrial applications
- Other characteristics
- high-torque, low-noise, low-vibration, multi-speed, UL certified
- Power
Max.: 15 kW
(20.394 hp)3.5 kW, 6.5 kW
(4.759 hp, 8.838 hp)- Rotational speed
Min.: 650 rpm
(4,084.07 rad.min-1)Max.: 1,460 rpm
(9,173.45 rad.min-1)705 rpm, 1,405 rpm
(4,429.65 rad.min-1, 8,827.88 rad.min-1)
Description
Motors with high torque, low noise and vibration
Dahlander 2-speed windings.
Magnetic core designed for high starting torque.
UL (cURus) certification available.
Motors designed for high torque combined with low electrical noise and vibration levels. Due to the housing and the shape of the machine, these problems are normally amplified.
A range of UL cURus certified motors is available for operation in the USA and Canada.
Technical Specifications
Magnetic core designed to provide high performance starting torque and maximum torque.
Dahlander 2-speed windings, calibrated to ensure high torque and low electrical noise;
Wide operating voltage and temperature range in class B;
Strict mechanical tolerances to obtain a low level of vibration and mechanical noise;
Specific execution B5-V3 or B14-V19;
Mechanical execution with reduced radial dimension.
If required, a version with cast iron flange and increased bearings is available for applications with a high radial load.
APPLICATIONS
• KNEADING MACHINES
• MIXER
