Signal converter IO222

analogUSBIO-Link

COMING SOON! IO222: Signal Converter Incremental >>> IO-Link Other available devices: • IO220 with analog input • IO221 with Strain gauge input • IO223 with SSI input Signal converter with incremental input and IO-Link interface for HTL/TTL/RS422 and NPN/PNP/NAMUR encoders and sensors. This IO-Link coupler transfers incremental signals to the IO-Link world. In addition, the conversion result can be called up via a USB port. The device parameterization is simple via the USB interface or via IO-Link using various engineering tools. • 1 incremental input (A, /A, B, /B) • for HTL/TTL/RS422 for NPN/PNP/NAMUR encoders and sensors • optionally 3 control inputs for PNP signals [10 ... 30 VDC] • IO link interface • Power supply 12 ... 30 VDC • Compact housing for mounting on 35 mm DIN rail (according to EN 60715) • USB interface for programming
