Display
Brightness (cd/m2) 250 250
Contrast Ratio 1000:1 1000:1
Support Colors 16.7M 16.7M
Pixel Pitch (H/Vmm) 0.264 x 0.264 0.264 x 0.264
Viewing Angle H: 170 degree
V: 160 degree H: 170 degree
V: 160 degree
System Processor
Frequency 2.0 GHz, up to 2.42 GHz 2.40 GHz
L2 Cache 2MB 3MB
CPU Type SoC SoC
Ethernet
Controller 1 x Intel® I210-AT GbE LAN 1 x Intel® I210-AT GbE LAN
Expansion Slot
Mini-PCIe 1 x Full-size 2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder)
(Mini-PCIe2 Slot w/ mSATA)
Storage
SATA 1 x 2.5" HDD/SSD (Default 128GB SSD) 1 x 2.5" HDD/SSD (Default 128GB SSD)
mSATA 1 (Shared with Mini-PCIe2)
I/O Interface
RJ-45 1 1
USB 2 x USB 2.0 2 x USB 2.0
Serial 1 x COM
COM1: RS-232, w/o power 1 x COM
COM1: RS-232, w/o power
Power Supply
DC Input DC-in 12V DC-in 12V
Environment
Operating Temperature 0° ~ 50°C 0° ~ 50°C
Operating Humidity 10% ~ 90% non-condensing 10% ~ 90% non-condensing
Storage Humidity 10% ~ 90% non-condensing 10% ~ 90% non-condensing
Storage Temperature -20° ~ 60°C -20° ~ 60°C
Physical Characteristics
Dimensions 425mm x 356mm x 90mm 425mm x 356mm x 90mm
Weight 9.0 Kg 9.0 Kg
Certification
EMC FCC, CE Class B FCC, CE Class B
