3.5" SBC MS-CF17 series

INFINEON13th Generation Intel® Core™Intel® Core™ i5-1335UE

The MSI MS-CF17 is a 3.5" Single Board Computer (SBC) designed for fanless, ultra low-power, high-performance applications, and capable of operating in wide temperature ranges. It utilizes the 13th Gen Intel® Raptor Lake-P Embedded/Industrial SKU series processors. The board supports up to 32GB of memory through a single DDR5 5200 MHz SODIMM slot. It enables quadruple independent displays via four HDMI ports and one LVDS/eDP. Networking capabilities include four 2.5GbE LAN ports with RJ-45. Expansion options feature an M.2 B Key (with NANO SIM-holder), an M.2 E Key, an M.2 M Key, and one SATA 3.0 port for storage. Connectivity options include four USB 3.2 Gen 2 ports, four USB 2.0 ports, four COM ports (RS-485), DIO, and audio. The board also integrates onboard TPM 2.0 for enhanced security and supports a wide voltage DC-IN range of 12-24V with Over-Current Protection (OCP) and Over-Voltage Protection (OVP).
