DC voltage transducer HVT 300-DV
DIN railprogrammableshunt monitoring

DC voltage transducer - HVT 300-DV - Mütec Instruments GmbH - DIN rail / programmable / shunt monitoring
DC voltage transducer - HVT 300-DV - Mütec Instruments GmbH - DIN rail / programmable / shunt monitoring
Add to favorites
Compare this product


Characteristics

Electrical characteristics
DC
Other characteristics
DIN rail, programmable, shunt monitoring, SIL2
Voltage

Min.: 0 V

Max.: 0.07 V

Description

The HVT 300-DV is a SIL2 certified voltage transducer for shunt monitoring. The HVT300-DV voltage transmitter is designed to measure high currents across a shunt resistor and to switch freely configurable alarms and emergency stop. It is redundant and certified according to SIL2. The HVT 300-DV has 2 freely configurable alarm relays and 2 SIL relays as well as an analog 4-20mA output. It can be freely configured via USB using software. Numerous monitoring functions, such as cable break monitoring or a memory check, ensure error-free operation. A typical application for the HVT 300-DV is the monitoring of currents around electrolysers and fuel cells. For example, it is often used to monitor the rectifiers upstream of an electrolyzer to ensure that a minimum current is flowing, as otherwise safety hazards may occur in the electrolyzer. FEATURES: - Redundant voltage input 0-70mV DC with 10 kΩ per channel. - Voltage transmitter in DuoTec technology with self-monitoring according to IEC/EN 61508 - Certified according to IEC 61508 SIL2 - FIT = 37 - Measuring range: 0-max. 70mV DC - Output: 0/4-20mA - 2 individually adjustable limit values (2 relay contact outputs for parameterization of switching thresholds / alarm) - 2 error alarms - Test voltage 4,3kV AC, working voltage 1000VAC/DC at overvoltage category II, pollution degree 2 IEC 61010-1 - Safe galvanic isolation between power supply, input and output - RS 485 Modbus via DIN rail contact - USB 2.0 interface - Configuration ON-LINE via WINDOWS software - Power supply 24VDC - Design: DIN rail, DIN EN 50022
