Concrete block making machine MVS-3615

automatic

MVS 3615 Block and Paverstone Machine is a specific design machine for block, interlock production which works fully automatic. The machine is programmed by PLC computer. All kinds of blocks, curbstones, paverstones can be produced by changing moulds. 20cm block can be produced 15, interlock paverstones can be produced 36 units in one press. Moulds are changing easly and take short time period by our new innovation mould changing system . Vibration on mould is expanded uniformly, because of using pneumatics bellow mould connections, Easy maintenance and service Machine Weight - 20000Kg Hydraulic Pump Power - Full Automatic - 30kw120lt + 4kw19lt + 11kw + 59lt/min Semi Automatic - 22kw60lt + 4kw19lt/min Manual - 20kw 59lt/min Hydraulic Oil Capacity - 1000lt Machine Mortar Bunker Capacity - 2x2000dm³ Machine Dimensions - 2900x8000x2700mm Upper Vibration Power - 4×0,72kW Lower Vibration Power - 4x6kW Total MachinePower Usage - Full Automatic - 71.8kW Semi Automatic - 52.8kW Manual - 46.8kW Minimum Product Height - 60mm Maximum Product Height - 300mm Vibration Press Power - 70kN Press Capacity - 7500kg-100bar The Number of Product on a Pallette - 36 pcs interlock, 15 pcs block 200x400x200mm Wooden Pallet Dimensions - 1400x1200x45mm
