ARM Cortex-M4 SoM MYC-LMA35 series

USB 2.0gigabit EthernetDDR3L SDRAM

The MA35D1 processor is based on dual 64-bit Arm Cortex-A35 cores with speed up to 800 MHz, and one 180 MHz Arm Cortex-M4 core. It integrates a TFT-LCD display controller, supporting 1920 x 1080@60FPS, and is equipped with a 2D graphics accelerator, JPEG and H.264 decoder, capable of supporting 1080P video playback. The MYC-LMA35 System-On-Module (SOM), a compact device measuring 37mm x 39mm, offers exceptional reliability for your upcoming embedded design projects. It's driven by the robust Nuvoton NuMicro® MA35D1 processor (MA35D16A887C/MA35D16AJ87C), which boasts dual 64-bit Arm Cortex-A35 cores with speed up to 800 MHz, alongside a 180 MHz Arm Cortex-M4 core. This processor comes equipped with a BGA package incorporating DDR3L memory. The MYC-LMA35 SOM comes standard with either 256MB NAND Flash or 8GB eMMC storage, both of which be customized to suit your specific needs. A versatile 252-pin LGA expansion interface enables a wide range of peripheral and IO signals, maximizing the potential of the MA35D1 processor. With advanced and high-speed connectivity interfaces such as Gigabit Ethernet, SDIO3.0, USB 2.0 HS, and CAN FD, it is ideally suited for edge gateway and new energy applications. Additionally, the inclusion of an LCD display controller, a 2D graphics engine, and JPEG and H.264 decoders make it an excellent choice for HMI applications. The MYC-LMA35 is ready to run the Linux Operating System. MYIR provides an extensive software package which includes kernel and driver source codes, as well as compilation tools, enabling users to start their development quickly and easily.
