3-axis CNC machining center YJ-VMC850verticalBT 40CAT40
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- vertical
- Spindle mount
- BT 40, CAT40
- Number of tool stations
- 24 tools
- X travel
850 mm
(33.46 in)- Y travel
510 mm
(20.08 in)- Z travel
560 mm
(22.05 in)- Rotational speed
8,000 rpm
(50,265 rad.min-1)- Power
7.5 kW, 11 kW
(10.2 hp, 14.96 hp)- Work feed X-axis
24,000 mm/min
(16 in/s)- Work feed Y-axis
24,000 mm/min
(16 in/s)- Work feed Z-axis
24,160 mm/min
(16 in/s)- Table load capacity
750 kg
(1,653 lb)- Tool weight (max)
6 kg
(13.2 lb)- Weight
5,300 kg
(11,684.5 lb)- Overall length
2,900 mm
(114.2 in)- Overall width
2,420 mm
(95.3 in)- Overall height
2,850 mm
(112.2 in)
Description
travel
Spindle nose to the desktop 140 ~ 700 (5.5 ~ 27.5 inches) mm
Spindle center to cylinder 575 (22.6 inches) mm
table
Table size is 1,000x500 (39.3x19.6 inches) mm
T slot (size / number / min) 18x5x100mm
spindle
Transmission gear head
Feed rate
Cutting feed speed 1 ~ 10 M / min
Automatic tool change
maximum. Tool diameter full: 100 mm
Next empty: 150 mm
maximum. Tool length 300 mm
CNC controller and motor
CNC Controller Mitsubishi (* FANUC / SIEMENS / HEIDENHAIN)
Shaft motor 2 kilowatts
Coolant
Coolant pump 0.75 HP
Coolant tank capacity 230 L
Air and power
Air source 6 kg / square meter
Power 15 KVA
Manufacturers reserve the right to make changes to their designs, specifications, institutions, etc., to improve machine performance. Specifications are subject to change without notice.
