CNC turning center YJ-CK6140A2-6A2-8
Add to favorites
Compare this product
Characteristics
- Control type
- CNC
- Spindle mount
- A2-6, A2-8
- Diameter
360 mm, 500 mm, 800 mm
(14.17 in, 19.69 in, 31.5 in)- Spindle speed
Min.: 30 rpm
(188.496 rad.min-1)Max.: 1,600 rpm
(10,053.096 rad.min-1)- Maximum part length
Min.: 500 mm
(20 in)Max.: 3,000 mm
(118 in)- Axe X
330 mm, 350 mm, 450 mm
(13 in, 14 in, 18 in)- Axe Z
Min.: 500 mm
(20 in)Max.: 3,000 mm
(118 in)- Nominal power
3.5 kW, 7.5 kW, 11 kW
(4.8 hp, 10.2 hp, 15 hp)- Overall lenght
1,740 mm, 2,100 mm, 2,420 mm, 2,860 mm, 4,830 mm
(69 in, 83 in, 95 in, 113 in, 190 in)- Overall width
1,210 mm, 1,600 mm
(48 in, 63 in)- Overall height
1,650 mm, 1,830 mm
(65 in, 72 in)- Weight
Min.: 1,275 kg
(2,811 lb)Max.: 5,400 kg
(11,905 lb)
Description
The largest swing on the board diameter Φ 150mm Φ 280mm Φ560mm
Rail span 260mm 400mm 460mm
Spindle through-hole diameter Φ 60mm MT6 Φ86mm / Φ105mm
Spindle taper MT6 Φ 100mm 1:20 Φ90mm 1: 20 / Φ110mm 1:20
Chuck 8 "10" 15 "
Turret number of jobs 4 or 6 or 8, the first row of knife 4 or 6 or 8 4 or 6 or 8
The largest section of the cutter 20 * 20mm 25 * 25mm 25 * 25mm
Tailstock sleeve travel 100mm 150mm 235mm
Tailstock sleeve diameter / taper Φ50mm / MT4 Φ75mm / MT4 Φ90mm / MT5
Cooling pump power 120w 180w 250w
Packing size L * W * H 1960 * 1410 * 1990mm 2300/2620/3060/3520 * 1800 * 2030mm 3520/4030/5030 * 1760 * 2030mm
Gross weight 1450KG 3000/3450 / 3650KG 4500/5000 / 6000kg
