3-axis milling machine YJ-X6323

verticalvariable speed

Table Dimensions T-slot (Q size x size) for table 230x1067mm (9 "x 42") Table 3x16mm (3x0.629 ") Longitudinal travel X-axis Manual 762mm (30") car 682mm ) Cross Travel (Y-Axis) 305 mm (12.007 ") Knee Vertical Travel Z-axis 406 mm (15.984") Ram Travel 390 mm (15.354 ") Guell Travel 127 mm (5") Spindle Taper NST # 30 / R8 (option NST # 40) Spindle to table nose 34 to 440 mm (1-3 / 8 "to 17-3 / 8") Spindle center to column 154 to 544 mm (6 "to 21.4") Turn 360 R & L +/- 45 ゜ Tilt (up and down) +/- 45 ゜ Spindle motor 3HPX axis Motor options: Power Lifting motor Zero quail feed 0.04~0.08~0.14mm / rpm (0.0015 "~ 0.003" ~ 0.006 ") Spindle speed step 50Hz low: 66 ~ 270 Hi: 550 ~ 2270 60Hz Low: 80~325 Hi: 660~2720 Variable Speed Head 50Hz Low: 50~420 Hi: 420~3750 60Hz Low: 60~500 Hi: 500~4500X Axis Fast Zero Lift Motor Speed Zero Total Height 2105 mm (82.874 ") Overall Depth 1618 mm (63.7") Overall Width 1497 mm (58.937 ") Net Weight 950Kgs (2200lbs)
