★ Operating Temperature Range -30~85°C
★ AG Coating Surface Treatment
★ Optional Auto Dimming Function (with Light Sensor)
★ Made in Taiwan, 3 Years Warranty, Designed for Harsh Environments
Display Specification
Panel Process - TN Type, Normally Black
Visible Area - 337.9x270.3 mm
Display Ratio - 4:3
Color Depth - 16.7M Colors
Brightness (nits) - 350 / (Optional) 1000 / (Optional) 1500 nits
Contrast Ratio - 800:1
Pixel Pitch - 264x264 um
Response Time - 30 msec.
Viewing Angle - 80°/80°/60°/80°
Backlight Lifetime - >50000 HRS
Operating Temp. - -30°~85°C
Storage Temp. - -30°~85℃
Allowed Touch Points - 10 points - Surface Treatment - AG Coating
Interface - USB - Thickness of Cover Lens - 2.0±0.2mm
IK Ratings - IK07 - Hardness of Cover Lens - 7H
Touch Options (Resistive)
Technology - Resistive - Transparency - 80%±5%
Allowed Touch Points - 1 points - Surface Treatment - AG Coating
Interface - USB - Hardness of Cover Lens - ≧3H
