Ball valve GB1A seriesleverpetroleumfor gas
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever
- Media
- petroleum, for gas, for air, for water
- Body$
- threaded, 2-piece
- Applications
- for the petroleum industry
- Material$
- brass
- Other characteristics
- ANSI, quarter-turn
- DN
Max.: 1 in
Min.: 0.125 in
- Pressure
41.4 bar
(600.5 psi)
Description
The NIBCO® brass gas ball valve is recommended for use with indoor gas appliance service. The two-piece valve meets the standards for indoor gas appliance connections, and is certified for use with natural, manufactured, mixed, liquefied petroleum and LP gas/air mixtures.
RPTFE seat
FIP x FIP end connections
Not for water service
1/2 psi for indoor appliance connections per ANSI Z21.15 and CSA 9.1
5 psi for indoor shutoff per CGA 91-002 and ASME B16.44
