Push-to-lock valve RV series
manualflow regulatorfor air

Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air
Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air
Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air - image - 2
Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air - image - 3
Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air - image - 4
Push-to-lock valve - RV series - NIHON PISCO CO., Ltd. - manual / flow regulator / for air - image - 5
Add to favorites
Compare this product


Characteristics

Operation
manual
Function
flow regulator
Media
for air
Body
in-line, small, right-angle
Applications
for pneumatic cylinders
Associated function
speed regulator
Other characteristics
push-to-lock
DN

4 mm, 6 mm, 8 mm
(0.157 in, 0.236 in, 0.315 in)

Pressure

Max.: 1 MPa

Min.: 0 MPa

Temperature

Max.: 60 °C
(140 °F)

Min.: 0 °C
(32 °F)

Description

Push-lock knob for easy and reliable pressure adjustment. This prevents the lock nut from loosening due to shaking of the machine. The new structure increases the flow rate by about 1.3 times compared to the no push-lock model. Furthermore, the pressure fluctuation is reduced. More stable pressure supply is now possible. Equipped with a relief mechanism for convenient adjustment of equipment. With reverse flow mechanism. Can be installed between a solenoid valve and an actuator and used as a check-type regulator. A type with a pressure gauge is also available. Mounting dimensions of union type are compatible with no push-lock regulator, RVU and RVUM. For price options, please contact our distributor near your office. https://www.pisco.co.jp/en/company/network/
