Flow regulator valve JSD seriesneedlemanualfor air
Add to favorites
Compare this product
Characteristics
- Type
- needle
- Operation
- manual
- Function
- flow regulator
- Media
- for air, for compressed air
- Body
- female, male, small, right-angle
- Applications
- for industrial applications, for pneumatic cylinders
- Associated function
- speed regulator
- Other characteristics
- compact, push-in, quick-connect
- DN
Min.: 3 mm
(0.118 in)Max.: 12 mm
(0.472 in)- Pressure
Min.: 0.1 MPa
Max.: 0.9 MPa
- Temperature
Min.: 0 °C
(32 °F)Max.: 60 °C
(140 °F)
Description
It prevents unnecessary manual adjustments during the operations.
Use a slot screwdriver to adjust the needle (speed adjustment).
Design without an external needle for speed adjustment.
Approx. 2/3 height of the conventional Speed Controller.*
Suitable for a small space. *Compared to the max. height of the conventional Speed Controller.
Selectable from 2 types.
360°rotatable resin body (Elbow type). 360°rotatable resin body and push-in fitting part (Free type). Free direction for piping.
For price options, please contact our distributor near your office. https://www.pisco.co.jp/en/company/network/
