Flow regulator valve JSD seriesneedlemanualfor air
Add to favorites
Compare this product
Characteristics
- Type
- needle
- Operation
- manual
- Function
- flow regulator
- Media
- for air
- Body
- male, right-angle, PBT
- Other characteristics
- compact, push-in
- DN
Max.: 12 mm
(0.472 in)Min.: 3 mm
(0.118 in)- Pressure
Max.: 0.9 MPa
Min.: 0.1 MPa
- Temperature
Max.: 60 °C
(140 °F)Min.: 0 °C
(32 °F)
Description
It prevents unnecessary manual adjustments during the operations.
Use a slot screwdriver to adjust the needle (speed adjustment).
Design without an external needle for speed adjustment.
Approx. 2/3 height of the conventional Speed Controller.*
Suitable for a small space. *Compared to the max. height of the conventional Speed Controller.
Selectable from 2 types.
360°rotatable resin body (Elbow type). 360°rotatable resin body and push-in fitting part (Free type). Free direction for piping.
Catalogs
JSD series
10 Pages
JSD series
10 Pages
