5-axis CNC machining center HPM series
universalHSK-63HSK-100

5-axis CNC machining center - HPM series - Niles-Simmons Industrieanlagen - universal / HSK-63 / HSK-100
5-axis CNC machining center - HPM series - Niles-Simmons Industrieanlagen - universal / HSK-63 / HSK-100
5-axis CNC machining center - HPM series - Niles-Simmons Industrieanlagen - universal / HSK-63 / HSK-100 - image - 2
5-axis CNC machining center - HPM series - Niles-Simmons Industrieanlagen - universal / HSK-63 / HSK-100 - image - 3
Add to favorites
Compare this product


Characteristics

Number of axes
5-axis
Spindle orientation
universal
Spindle mount
HSK-63, HSK-100
Number of tool stations
32 tools, 120 tools, 64 tools
Applications
for matrices
Other characteristics
high-performance, high-precision, with pallet changer
X travel

1,000 mm, 1,350 mm, 1,850 mm
(39.37 in, 53.15 in, 72.83 in)

Y travel

1,150 mm, 1,400 mm
(45.28 in, 55.12 in)

Z travel

700 mm, 815 mm, 895 mm, 910 mm
(27.56 in, 32.09 in, 35.24 in, 35.83 in)

Rotational speed

10,000 rpm, 15,000 rpm, 18,000 rpm, 24,000 rpm
(62,832 rad.min-1, 94,248 rad.min-1, 113,097 rad.min-1, 150,796 rad.min-1)

Power

30 kW, 34 kW, 38 kW
(40.79 hp, 46.23 hp, 51.67 hp)

Work feed X-axis

30,000 mm/min, 40,000 mm/min
(20 in/s, 26 in/s)

Work feed Y-axis

30,000 mm/min, 40,000 mm/min
(20 in/s, 26 in/s)

Table load capacity

1,600 kg, 4,000 kg
(3,527 lb, 8,818 lb)

Description

NILES-SIMMONS designs, deve­lops and manu­fac­tures Uni­ver­sal High-Pre­cision Mil­ling Cen­tres of the High Perfor­mance Milling series. The HPM-machi­nes are well sui­ted for pro­duc­tion of high-pre­cision work­pie­ces made of high-strength mate­ri­als, in par­ti­cu­lar, for the tool and die indus­try as 5‑axis machine, optio­nally equip­ped with pal­let chan­ger. Up-to-date high speed motor dri­ven spind­les, directly dri­ven rotary and swi­vel axes and the sturdy machine body offer best pre­re­qui­si­tes for effi­ci­ent and pre­cise pro­duc­tion with modern tools.
