Revolving door

slidingsafetyautomatic

General description of automatic glass revolving door Door Type: 3 in 1 Balanced 2 wing automatic revolving door Drive Type: Overhead Diameter: 3600, 4200, 4800 Passage Height: 2200 std - up-to 2800 Canopy Height: 340 std - up-to 1200 Main functions and features of two wing automatic glass revolving door: 1.Door type : 3 in 1 balanced two wing automatic revolving door, that is, automatic revolving door + automatic sliding door + balanced door 2. Adjustable speed range, low speed push pad button for disabled 3. Remote control and maintenance function 4. 4 +4 mm arc laminate glass 5.Voice prompt function, ensure passenger's security 6. Infrared safety sensor + infrared foot stable, protect passenger's safety maximally Technical specifications of two wing automatic glass revolving door: Power supply 220V/50HZ Rated power 700W Rated current 10A Sliding door drive unit 100W Revolving door drive unit 250W X 2=500W Standard speed adjustment range(revolving door) 3-4 r/min Low speed adjustment range(revolving door) 1-2 r/min Mechanical life 100000hr Dimensions of two wing automatic glass revolving door: Internal Diameter 3600 4200 4800 External Diameter 3688 4288 4888 Passage Height 2200 2200 2200 Canopy Height 340 340 340 Overall Height 2540 2540 2540 Opening Width 1800 2100 2400 Sliding Door Opening Width 1100 1400 1700 Balanced Door Width 1800 2100 2400
