Technical specifications of 3 wing automatic revolving door with showcase:
Power supply
220~230V/50~60HZ
Rated current
10A
Rated power
400W
Revolving door drive unit
250W X 2=500W
Spot lights
50W
UPS power consumption
1000VA
Standard speed adjustment range
3-4 r/min
Low speed adjustment range
1-2 r/min
Expected lifespan
100000hr
Dimensions of 3 wing automatic revolving doors with showcase:
Internal Diameter (mm)
2100
2400
2700
3000
3200
External Diameter (mm)
2188
2488
2788
2088
3288
Opening Width (mm)
924
1074
1224
1374
1474
Passage Height (mm)
2200
2200
2200
2200
2200
Canopy Height (mm)
300
300
300
300
300
Overall Height (mm)
2500
2500
2500
2500
2500
