Drawing number
3511-00
Dimension floor bolting
M 20
Alternativ floor bolting
M16 / M24
Spacing washer to push-in cam
see accessories
Fine adjusting range
7 mm
Maximum adjustment load
150 kN
Maximum torque
60 Nm
Torque per 10 kN
4 Nm
Hexagonal wrench for adjustment
17 mm
Height adjustment per adjusting screw turn
0,375 mm
Flexibility/rigidity
5000 N/µm
Weight of wedge
6,2 kg
