Precision leveling wedge DK-2/10 + AP 10x10, M20x95 (190)
adjustablewith screw on bolt

precision leveling wedge
precision leveling wedge
Add to favorites
Compare this product


Characteristics

Applications
precision
Other characteristics
adjustable, with screw on bolt

Description

Drawing number 3211-07 Kind of floor bolting 2 x adhesive anchor Alternativ floor bolting to M24 Spacing washer to push-in cam see accessories Fine adjusting range 10 mm Maximum adjustment load 120 kN Maximum torque 72 Nm Torque per 10 kN 6 Nm Hexagonal wrench for adjustment 17 mm Height adjustment per adjusting screw turn 0,546 mm Flexibility/rigidity 5000 N/µm Weight of wedge 11,2 kg
