Drawing number
3241-01
Dimension floor bolting
M20 x 100 (125)
Kind of floor bolting
screw on bolt
Alternativ floor bolting
M16
Spacing washer to push-in cam
see accessories
Fine adjusting range
10 mm
Maximum adjustment load
120 kN
Maximum torque
72 Nm
Torque per 10 kN
6 Nm
Hexagonal wrench for adjustment
17 mm
Height adjustment per adjusting screw turn
0,546 mm
Flexibility/rigidity
5000 N/µm
Weight of wedge
6,8 kg
