Drawing number
2029-01
Dimension floor bolting
M16 x 320
Kind of floor bolting
Adhesive anchor
Alternativ floor bolting
M20 x 320
Fine adjusting range
7 mm
Maximum adjustment load
70 kN
Maximum torque
35 Nm
Torque per 10 kN
5 Nm
Hexagonal Allen key for adjustment
SW 10
Height adjustment per adjusting screw turn
0,275 mm
Vibration protection, nitril vulcanised on
Vulcanised layer 90° Shore
Weight of wedge
2,0 kg
