Ampoule filling machine NAFS-180

automatic

N.K Industries based in Ahmedabad, Gujarat is broadly acknowledged as a leading manufacturer & supplier of Automatic Eight head vertical Ampoule filling and sealing machine which is its endeavour to the highest quality of technology in injectable SVP (Small Volume Parentéral) segment. Due to the Advance manufacturing technique, our machine assures accurate filling, lowest breakage ratio & superior sealing. The Vertical Ampoule filling and sealing machine can work with 1 ml to 10 ml ampoule and has the capability to deliver the higher output around 280 to 300 Ampoules/ minute for 1ml and 2 ml ampoule. The Exceptional features of the machine are "No Ampoule - No Filling System", "Fine volume setting of individual syringe. Automatic Eight Head Vertical Ampoule Filling And Sealing Machine Is Equipped With Following Highly Advanced Features: CGMP Model. Imported Gear Box And Gear Motor. As A Optional In Feed Wire Mesh Conveyor For Transfer Of Ampoules To The Filling Operation (Can Be Attached Online With Tunnel) Machine Frame Made Using AISI 304. Ail Contact Parts With Liquid Made Using AISI 316L. Foaming & Spillage Is Avoided Due To Diving Nozzles. Output Speed Of 300 Ampoules/Min For 2 Ml. Ampoule Machine Direction From Right To Left. Elegantly Designed Aluminium Rack To Transfer The Ampoules To The Filling And Sealing Station. Precisely Centering Of Ampoules Neck While Passing Through The Various Stage Of Operation Like Gas Flushing, Filling &. Sealing Of Ampoules. Pre & Post Gasing Unit
