Combustion engine forklift FD series
ride-onindustrialcounterbalanced

Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced - image - 2
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced - image - 3
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced - image - 4
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced - image - 5
Combustion engine forklift - FD series - Noblelift Intelligent Equipment Co., Ltd. - ride-on / industrial / counterbalanced - image - 6
Add to favorites
Compare this product


Characteristics

Motor type
combustion engine
Operator
ride-on
Applications
industrial
Other characteristics
4-wheel, counterbalanced
Carrying capacity

Min.: 2,500 kg
(5,511.6 lb)

Max.: 3,500 kg
(7,716.2 lb)

Lifting height

Min.: 2,000 mm
(78.74 in)

Max.: 4,000 mm
(157.48 in)

Overall width

1,150 mm, 1,210 mm
(45.3 in, 47.6 in)

Overall length

2,560 mm, 2,620 mm, 2,700 mm, 2,770 mm
(100.8 in, 103.1 in, 106.3 in, 109.1 in)

Load center distance

500 mm
(19.7 in)

Weight without load

3,400 kg, 3,635 kg, 4,340 kg, 4,710 kg
(7,495.7 lb, 8,013.8 lb, 9,568.1 lb, 10,383.8 lb)

Axle loading with maximum load front

4,760 kg, 5,385 kg, 6,520 kg, 7,250 kg
(10,494 lb, 11,871.9 lb, 14,374.1 lb, 15,983.5 lb)

Axle loading with maximum load rear

640 kg, 650 kg, 820 kg, 920 kg
(1,411 lb, 1,433 lb, 1,807.8 lb, 2,028.3 lb)

Axle loading without load front

1,500 kg, 1,540 kg, 1,690 kg, 1,750 kg
(3,306.9 lb, 3,395.1 lb, 3,725.8 lb, 3,858.1 lb)

Axle loading without load rear

1,860 kg, 2,135 kg, 2,590 kg, 3,020 kg
(4,100.6 lb, 4,706.9 lb, 5,710 lb, 6,658 lb)

Track width front

970 mm, 1,000 mm
(38.2 in, 39.4 in)

Track width rear

980 mm
(38.6 in)

Overall height with mast raised

4,090 mm, 4,177 mm, 4,182 mm
(161 in, 164.4 in, 164.6 in)

Height to top of overhead guard

2,180 mm, 2,205 mm
(85.8 in, 86.8 in)

Turning circle radius

2,180 mm, 2,230 mm, 2,450 mm, 2,520 mm
(85.8 in, 87.8 in, 96.5 in, 99.2 in)

Travel speed

17 km/h, 18 km/h, 19 km/h
(10.6 mph, 11.2 mph, 11.8 mph)

Lifting speed

430 mm/s, 460 mm/s, 490 mm/s, 520 mm/s

Lowering speed

380 mm/s, 400 mm/s, 420 mm/s

Rated drawbar pull

15 kN, 17 kN

Gradeability

18 %, 20 %

Maximum operating pressure

18.5 MPa

Description

Under the request of our dealers, Noblelift combines the experience of the forklifts industry in China and the latest forklift technologies globally to present to our partners the Noblelift environmental-friendly IC forklifts range with excellent safety, reliability, ergonomics & comfort and easy maintenance. Noblelift IC forklifts adopt the mast system of Q series electric forklifts range for easy exchange, easier service and less parts inventory. Selected top brand components in the industry make sure the best reliability and performance of the trucks. Ergonomic design such as optimized operating device structure & layout, with the clear displaying and ergonomic location of the instrument, the operator can know the truck information in time, which reduces driving fatigue and makes long hours of operation effortless. • With 100% pivot steering and returning, systems the truck has good maneuverability in narrow areas. The truck has small turning radius, easy steering, good gradeability and perfect maneuverability. • Tilting cylinder is located below the floor panel of the driving cab, widening low anti-slip step and enlarging operation space at foot provide comfort entry and exit operation. • Wide view through the optimized mast and hydraulic System, the forks with intelligent buffer, protect the ground and goods from damage. • The ratchet parking brake is specially developed. The operational force is reduced by 30%. Optional Operator Presence System (0B) incorporates lifting/tilting and traveling locking function.VVhen the leaves the seat, the system automatically locks lifting/tilting and disables traveling to ensure safety.
