Bell-shaped bearing unit 23500
Add to favorites
Compare this product
Characteristics
- Type
- bell-shaped
- Inside diameter
Max.: 11 mm
(0.43 in)Min.: 3.3 mm
(0.13 in)- Outside diameter
Max.: 30 mm
(1.18 in)Min.: 5 mm
(0.2 in)- Length
Max.: 139 mm
(5.47 in)Min.: 34 mm
(1.34 in)
Description
igubal® pillow block bearings
Material:
Housing igumid® G.
Swivel ball iglidur® W300
Version:
black.
Note:
The ability to pivot allows pillow block bearings to compensate for misalignment and possible shaft deflection. They are easy to install and suitable for the accomodation of rotating, oscillating and linear movements.
igubal® pillow block bearings are maintenance free and conceived for dry running condition.
Assembly:
These pillow block bearings are designed for mounting with 2 screws.
The ID tolerance is E10. The matching shaft should have a tolerance of h6 to h9.
