Diaphragm seal with flange connection 2 series

process

Designed to isolate the pressure measuring instrument from corrosive or viscous process media Utilize an all welded, all metallic housing design to eliminate potential leak paths For use with gauges with dial sizes of 2-1/2" and smaller, and pressure ranges no less than 100 psig Housing and diaphragm offered in a variety of materials to suit most applications A flushing port is available to clean wetted areas and prevent process media build up Consider instrument size, pressure range, media composition, ambient and operating temperature, and maximum working pressure when selecting Capillaries and cooling elements are available for elevated process temperatures, see options & accessories below Fill fluid must be compatible with process media; i.e. Glycerin may become volatile in conjunction with a strong oxidizing agent such as chlorine, forms of oxygen or peroxide and nitric acids Seal type - Threaded with welded diaphragm Instruments - Type - Size - Minimum Pressure - Maximum Pressure Gauges - 2-1/2" - 0 psig to 100 psig - 0 psig to 2,500 psig (25H - 5,000 psig) Transducers - — - 0 psig to 60 psig - 0 psig to 2,500 psig (25H - 5,000 psig) Switches - — - 0 psig to 60 psig - 0 psig to 2,500 psig (25H - 5,000 psig)
