Pt100 temperature transmitter TxMini

Pt10003-wire4-20 mA

The TxMini family of temperature transmitters have compact dimensions and practical connections. They are available without a connector, with an M12 connector, or with a DIN43650 connector. They deliver the measured temperature via 4 to 20 mA signals or an RS485 serial interface via the Modbus-RTU protocol. They are easily integrated into existing networks for communication with PLCs or SCADA systems. The TxMini is configured using SigNow software via the USB interface. For the RS485 versions, configuration is also done via Modbus commands, generated automatically from a SCADA system. Versatile and compact, these transmitters are the ideal solution for adapting sensors to any environment. • Resolution: 2 µA • Typical accuracy: 0.1 % @ 25 °C (77 °F) • Operating temperature: -40 to 85 °C (-40 to 185 °F), 0 to 90 % RH • Housing material: Polyamide • Configurable measuring range from -200 to 650 °C (-328 to 1202 °F) • Commissioning via SigNow software with TxConfig-USB configuration interface
