The TBM34 series is a ruggedised professional trackball. The unit has been specially designed for harsh industrial environment applications : the self-adjusting PTFE seal of the trackerball guarantees an IP65 static (ball in rest) protection grade. Carrier plates and housing are metal (aluminium and steel).
Panel mount (incl. alu carrier plate, electronics and cable)Intended for front panel mounting into users’ cabinet or panel with a minimum of required space and mounting depth. Operation of the trackerball is possible at all angles, from horizontal to vertical mounting position. The electronic parts on the backside are protected by a metal cover. A neoprene seal which can be fitted between the carrier and the customers panel, is delivered with each unit.
IP65 sealed trackballs
38 mm ball diameter for the highest precision in cursor control
Self-adjusting PTFE seal of the trackballs
Aluminium carrier plates covered by UV hardened, chemical resistant polyester
Combo PS/2 & USB output
