Anemometer display WM44-DRM

LED3-digitprogrammable

The WM44-DRM Wind speed Display is a device with high accuracy with 2 programmable threshold output. It is particularly designed to work with ANEMO4403 but it can work also with a huge range of anemometers. 2 programmable thresholds (ALARM 1 and ALARM 2). The device can be easy mounted on a front door of electric panel. Specially developed for tower cranes sector. Visual Display - 3 digit LED Display (height 14 mm) - 2 LED alarm status indicator (AL1 e AL2) - LED speed unit indicator (Km/h o Mph) - Automatic deactivation of the realy under the threshold level - Signalling by flashing display of intervention (AL2) - Selecting the mode for the alarm (intermittent, continuous, considered) Main Features - Available power supply: 230 Vac 50/60Hz - Current consumption equal / less than 3 VA - Signal input frequency from 1 to 750 Hz - from 5 to 35 Vcc or from 4 to 24Vca. - Voltage signal input 5 - 35 Vdc +-10% - Impedance input sensorANEMO4403 o Namur: 1000 Ω - Power supply output voltage sensor 10 or 20 Vcc (+-10%) - 2 thresholds programmable relay - Relay contact 4 A - 250 Vac - Operating temperature 0°C +60°C - Accuracy at 100 Hz + - 1% - Maximum measurable speed 999 Km/h - 610 mph - Weight 450 g Regulations Protection: - IP20 EMC: - EN 61000-6-2:2001 - EN 55022:2001, Class B
