CANopen IO module CT-5331
analognetworkautomation

CANopen IO module - CT-5331 - ODOT Automation - analog / network / automation
CANopen IO module - CT-5331 - ODOT Automation - analog / network / automation
CANopen IO module - CT-5331 - ODOT Automation - analog / network / automation - image - 2
Add to favorites
Compare this product


Characteristics

Signal type
analog
Bus
CANopen
Type
network
Applications
automation
Mounting
DIN rail

Description

Product Feature: The CANopen master module supports 1 x CAN interface , supports the CANopen master working mode . The CT-5331 could be applied with the I/O adapter modules , so it could convert CANopen into other protocols ,such as Modbus-TCP, Profinet, EtherCAT, Ethernet/IP, etc.When the module is used, input and output commands need to be configured in the IO Config software through the Type-C interface of the module. All slave devices that support the CANopen protocol can use this module to interconnect with the upper PLC or the upper computer, Such as: CANopen remote IO station, CANopen various sensors, CANopen drivers and so on. General parameters Power - Max.50mA@5.0Vdc Isolation - I/O to internal bus: opto-couple isolation (3KVrms) Field Power - Nominal:24Vdc, Range:19.2~28.8VDC Wiring - I/O Wiring:Max.1.0mm²(AWG 17) Mounting Type - 35mmDIN-Rail Size - 115*14*75mm Weight - 65g Environment Specification Operational Temperature: - -40~85℃ Operational Humidity: - 5%~95% RH(No Condensation) Protection Class: - IP20 CAN Parameters M/S/F:Channel Number: - 1Channel M/S/F:Interface - CAN M/S:Protocol - CANopen Conform DS301 V4.02 M/S/F:Working Mode: - CANopen Master M/S station: - 16 Slave station M/S Baud rate: - 10K~1Mbps
