Data connector 210

DINhexagonalstainless steel

Ruggedly constructed from 6061-T6 Aluminum: inherent corrosion resistance Optional washer: component reduction for in-tank coolers One piece machined body: compact space and lightweight Designed for maximum performance: 100% production leak tested Improved ergonomics and cleanliness: with rounded corners Controlled axial clearance: prevents micro leakage Minimum pressure drop: ensures optimum flow Robust retainer mechanism: low insertion force External ISO seal: leak prevention at thread interface Internal seal: leak prevention at tube interface TECHNICAL DATA OVERVIEW Material Body: SAE 6061-T6 Aluminum (UNS A96061, DIN W. Nr. 3.3211) Retainer: SAE Stainless Steel 302 (UNS S30400) Internal/External Seal Options Oetiker Quick Connectors (QC) are an innovative connecting solution for pressure lines carrying media. They enable significant savings in assembly time, space required, assembly costs to be made, reduced warranties, and reduced injuries due to repetitive motion. Thanks to tool-free assembly, Oetiker QC’s are an optimal solution for many applications and are particularly suitable as a connecting element for oil and / or coolant and heating lines to turbochargers, engines, and transmissions.
