Fiber optic combiner V-Linx™

compact

• Compact size • Supports aggregation of up to 72 units (60 units most common) • Uses multi-fiber connector interface • Integrated with V-Linx Cables at the factory • Field integration of V-Linx Cables optional The V-Linx™ Combiner aggregates the optical paths from up to six V-Linx Terminals (up to 72 individual units). Using the same compact chassis as the V-Linx Terminal, the V-Linx Combiner is configured with preterminated AccuFlex™ PLUS Optical Ribbon Interconnect Cable assemblies in the factory for quick set up and installation in the field (supporting 300 lbf (1335 N) of axial load). The cable provides excellent transmission performance, flexibility, and connectivity in a very small package (.33 in. (8.4 mm) diameter). The V-Linx Combiner provides all the necessary assistance to allow a single person to install the entire cable between floors. It uses multifiber push-on (MPO) connector technology which enables a very compact aggregation point from multiple V-Linx Terminals. Uniquely designed for dense, multifloor units, the V-Linx Spool and Play Solution can significantly reduce the manpower and time needed to install the network backbone with short length spool-and-play technology in MDUs. The V-Linx Spool and Play Solution comprises 4 major components: • V-Linx Fiber Distribution Hub (FDH) • V-Linx Combiner • V-Linx Terminal • EZ-Bend® Drop Assemblies
