The infrared thermometer optris CTlaser LT allows for exact temperature measurement on smallest objects from 0,9 mm at a distance of 70 mm. The IR thermometer optris CTlaser LTF is due to its short configuration time of only 9 ms perfectly suited for surveillance of quick working processes.
Both models offer a robust and premium-quality stainless steel measuring head with an innovative double laser sighting for an exact measuring field marking in every distance.
Measurement Specifications
• Optical resolution (90% energy):
75:1 CTlaser LT
50:1 CTlaser LTF
• Selectable focus (CT laser)1):CF1 0.9mm @ 70 mm
CF2 1.9 mm @ 150 mm
CF3 2.75 mm @ 200 mm
CF4 5.9 mm @ 450 mm
SF 16 mm @ 1260 mm
• Repeatability (at Tamb = 23 ± 5°C):±0.5 % or ±0.5°C2) (CTlaser LT)
±1 % or ±1°C2) (CTlaser LTF)
• Temperature resolution (NETD):
0.1 K (CTlaser LT)
0.5 K (CTlaser LTF)
• Emissivity / Gain (adjustable via programming keys or software): 0.100 – 1.100
• Transmissivity / Gain (adjustable via programming keys or software): 0.100 – 1.000
• Signal processing (parameter adjustable via software):
peak hold, valley hold, average, extended hold function with threshold and hysteresis
General Specifications
• Environmental rating: IP 65 (NEMA-4)
• Ambient temperature:
sensing head: -20°C … 85°C (50°C with laser ON)
electronics: 0°C … 85°C
• Storage temperature:
sensing head: -40°C … 85°C
electronics: -40°C … 85°C
• Relative humidity: 10 – 95%, non condensing
• Vibration: IEC 60068-2-6 (sinus shaped), IEC 60068-2-64 (broadband noise)
• Shock: IEC 60068-2-27 (25G and 50G)
• Weight:
sensing head: 600 g
electronics: 420 g
