Infrared thermometer CTlaser P7

digital°Cwith laser pointer

The infrared thermometer optris CTlaser P7 is perfectly suited for precise temperature measurement of thin plastic materials, e.g. PET, PU, PTFE, PA or CTA and for determination of temperatures of glass surfaces. It offers a broad temperature range from 0°C up to 710°C and can be employed in temperatures of up to 85°C without additional cooling. The IR thermometer for measurements of plastic foils and glass temperatures is capable of targeting smallest objects of 1.6 mm in a distance of 70 mm. Its standardized two-wire interface additionally allows for a reliable transfer of measurement data and easy integration into a PLC. Measurement Specifications • Optical resolution (90% energy): 45:1 • Repeatability (at Tamb = 23 ± 5°C): ±0.5% or ±0.5°C2) • Temperature resolution (digital): 0.5 K • Emissivity / Gain (adjustable via programming keys or software): 0.100 – 1.100 • Transmissivity / Gain (adjustable via programming keys or software): 0.100 – 1.100 • Signal processing (parameter adjustable via programming keys or software, respectively): peak hold, valley hold, average, extended hold function with threshold and hysteresis General Specifications • Environmental rating: IP 65 (NEMA-4) • Ambient temperature: sensing head: -20°C … 85°C (50°C with laser ON) electronics: -20°C … 85°C • Storage temperature: sensing head: -40°C … 85°C electronics: -40°C … 85°C • Relative humidity: 10 – 95%, non condensing • Vibration:IEC 60068-2-6 (sinus shaped), IEC 60068-2-64 (broadband noise) • Shock: IEC 60068-2-27 (25G and 50G) • Weight: sensing head: 600 g electronics: 420 g
