Flexible solar panel 001042
monocrystalline siliconblackIP68

Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68
Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68
Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68 - image - 2
Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68 - image - 3
Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68 - image - 4
Flexible solar panel - 001042 - OZO - monocrystalline silicon / black / IP68 - image - 5
Add to favorites
Compare this product


Characteristics

Technology
monocrystalline silicon
Other characteristics
black, flexible, IP68
Peak power (Wp)

180 W

Open-circuit voltage

20.9 V

Short circuit current

9.13 A

Max power voltage

24.7 V

Max power current

8.61 A

Module efficiency

20.12 %

Lenght

1,260 mm
(50 in)

Width

710 mm
(28 in)

Height

2 mm
(0 in)

Weight

3.5 kg
(7.72 lb)

Description

Monocrystalline cells up to 20.12% efficiency. ETFE (ethylene tetrafluoroethylene): a composite material with a high manufacturing quality that makes solar panels extremely robust. Panels protected by this ETFE coating will not be subject to delamination, cracking or corrosion. This coating also ensures optimum light transmission, which improves the efficiency of the solar panel. This protection has been used for many years in applications where durability and temperature resistance are a priority. Increases light absorption by more than 5%. The lamination material we use is Anti-Seawater-Corrosion and is particularly suitable for the construction of marine solar panels; for use on seacraft-boats, yachts, etc... Flexible solar panels provide a degree of versatility that cannot be achieved by glass solar panels. Their lightweight and flexible characteristics allow seamless integration on your vehicle. Seacraft: Boats, yachts, cruisers and riverboats. Land vehicles: Caravans, recreational vehicles, trailers, 4×4s, etc. Semi-rigid aluminium solar panel, PET laminates, semi-flexible solar panel Assembled from aluminium foil for the rear and laminated PET solar cells. This panel is also compatible with our OZO 300W and 600W MPPT boost chargers, allowing you to recharge your 36V, 48V battery with a single 12V panel. This panel is a flexible panel that can be bent up to 30°.
