Swing check valve FSDFSCWV1

fuelalloyaluminum

The fuel swing check valve is an inline, swing flapper check valve that has many uses; one of which is to prevent reverse fuel flow from the ejector pumps to the engine feed subsystem. The valve is spring-loaded to the normally closed position to provide motive flow line isolation from downstream equipment/lines when the - motive flow supply is non-operational. This elegantly simple design is extremely reliable and several variations of this valve have been - produced by Parker for over 30 years. - A fuel swing check valves is an ideal choice if surge pressures and any hammering effects are an important design consideration. This valve - is typically installed horizontally and with the hinge up so that in the unlikely event the torsional spring should break, the valve shall fail close. - With its low pressure drop and low leakage rate, this valve is an ideal choice when properly selected for the right application. - The material and finishes used in the construction of the valve and those of similar, previously qualified valves are unaffected by several - environmental conditions listed in RTCA DO-160 and MIL-STD-810. - APPLICATIONS - Commercial aircraft, military fighters and transports, business and general aviation. - FEATURES AND ATTRIBUTES: - Fundamental features of the fuel swing check valve include the following: - • Very low pressure drop - • Internal components are completely shielded by an aluminum alloy body from the environment - • Low Internal leakage
