Cartridge filter housing TTF series

for oilaluminumlow-pressure

The TTF Series features pre-filtration by means of a magnet column and a quick response bypass with low hysteresis. Maximum pressure 10 bar. Maximum flow 500 l/min. A second return port is an available option as is a filling port in the filter cover. Product Overview Items marked with an asterisk * in the drop-down menus are standard choices. The Parker Filtration TTF Series Return Line Filters TTF tank top mounted return line filters feature pre-filtration by means of a magnet column and a quick response bypass with low hysteresis. Thanks to the “In-to-Out” filter principle, contaminated oil cannot leak back into the system st element change. TTF filters are available in versions capable of handling flow rates up to 500 l/min. They can operate up to a maximum working pressure of 10 bar. Optional filling port i n filter cover, second return port and customised diffusers can be specified. Typical Applications: • Waste management trucks • Mobile cranes • Power packs • Wheeled loaders • Drilling equipment
