Water hose 2380M series

polyurethanepolyamidehigh-pressure

Parker Polyflex High Pressure 2380M Hoses are developed for High and Ultra High Pressure applications. The excellent handling increases operator efficiency and long service life reduces costly down times. Superior safety standards are applied for the benefit of the operator. Markets: • Water jet cutting (only hoses > 2000 bar) • All markets requiring pressures over 700 bar for their cleaning and cutting applications Features/Benefits: • Replaces steel pipe where flexibility is important • A manufacturing procedure applying water pressure to produce complex hollow parts made from pipe-like basic materials • Compact design hereby handling and space improvements • Compliant with DIN EN 1829-2 thus legal backup and approved safety hazard control • Excellent operator safety as a result of highest quality standards which are met • Design factor: > 2:1 Applications: • High pressure service for the construction and shipbuilding industry • For working pressure up to 110 MPa (15.950 psi) Technical specifications: • Pressure reinforcement: Two spiral layers and two open spiral layers of high tensile steel wire • Standard colour: black Weight 0,19 - 0,24 lb/ft 0,28, 0,35 kg/m Design Factor 4
