Oil strainer RS series

flangestainless steel

The RSF/RSW refrigerant strainers collect foreign materials and dirt in a refrigerant system at minimal pressure drop in order to minimize damage to or prevent malfunction of control valves. The RSF and RSW industrial type Refrigerant Strainers with stainless steel screens are designed especially for the protection of Industrial Refrigeration control valves from foreign materials present in refrigeration systems. The fine stainless steel mesh will collect particles as small as 0.009” in diameter (60 Mesh@ 0.0075” wire). Generous available screen area allows maximum dirt capacity at minimum pressure drop. The RSF strainers may be close coupled to Industrial Refrigeration valves having the same flange gasket size. Markets: • Industrial Refrigeration • Commercial Refrigeration Features and Benefits: • Drain Connection for Safe Cleaning • Generous Screen Area • Low Pressure Drop • Durable Filter Bags Available ¾” to 4” (20-100mm)- on RSF Strainers • RSF Type Strainers can be close coupled Application: • Refrigerant System
