Round anti-vibration mount X series
steelstainless steelepoxy

round anti-vibration mount
round anti-vibration mount
round anti-vibration mount
Add to favorites
Compare this product


Characteristics

Configuration
round
Material
steel, stainless steel, epoxy, plastic
Applications
marine
Static load

Min.: 10 daN

Max.: 450 daN

Diameter

Min.: 31.8 mm
(1.252 in)

Max.: 63.5 mm
(2.5 in)

Description

Marine shockproof holder, resilient, radially mounted. Steel mounting with excellent shock absorption capacity, highly resistant to fatigue. It is made of a stainless steel and epoxy resin sandwich which limits the amplification. Avantages ► Intrinsically stable under impact, that is to say that they allow the mass to return to its initial position; the system does not retain any plastic deformation or residual buckling when the stresses of the impact have disappeared. ► The suspended mass can therefore undergo several successive shocks without risk. However, the stability of the assembly must be checked beforehand in relation to the relative positions of the supports and the centre of gravity of the suspended mass. ► The PAULSTRA marine supports also offer excellent vibratory and acoustic performance. Specifications Marine support shall perform the following functions: ► Maintenance of the suspended mass in the absence of shock with a vibratory and/or acoustic insulation capacity; ► In case of shocks: limitation of force and/or displacement to acceptable values; ► After shocks: return of the suspended mass to its initial position.
