Impeller pump DB serieswaterelectricsubmersible
Add to favorites
Compare this product
Characteristics
- Technology
- impeller
- Fluid
- water
- Operation
- electric
- Priming
- submersible
- Mobility
- stationary
- Domain
- industrial
- Applications
- drainage
- Voltage
- 400 V, 230 V, 220 V
- Other characteristics
- built-in
- Flow
Max.: 650 l/min
(171.71183 us gal/min)Min.: 100 l/min
(26.41721 us gal/min)- Head
Max.: 11.4 m
(37'04" )Min.: 2 m
(6'06" )- Fluid temperature
Max.: 40 °C
(104 °F)Min.: 0 °C
(32 °F)- Height
461 mm
(18.15 in)- Weight
17 kg, 18.5 kg
(37.48 lb, 40.79 lb)
Description
Drainage pump with “Double-Channel” impeller for pumping waste waters and liquids with suspended solids; ideal for civil and household applications.The single-phase version with built-in capacitor and thermal protector can be equipped with a float switch.
