Butterfly valve BR 14t

pneumaticfor controlshut-off

Pneumatic control valve VALVE STYLE Butterfly valve USAGE Throttling service Low-pressure service On/off service Steam conditioning VERSION ANSI SUPPLY Pneumatic VALVE SIZE PRESSURE RATING Class 150 to Class 300 LINING without Special features Consisting of high-performance triple-eccentric control and shut-off butterfly valve as well as actuator DIN ISO 5211 interface as standard Butterfly valve body made of steel or stainless steel Lug-type and wafer-type bodies Tight shut-off in both directions Wide control range Low initial breakaway torque No friction Adjustable graphite packing TA Luft Blow-out-proof shaft Soft or metal seal Self-centering gasket Fire-safe according to API 607 Uninterrupted facing Face-to-face dimensions according to DIN EN 558, Series 16 Leakage requirements according to DIN EN 12266, API 598 or ANSI FCI 70-2-2006 Accessories Lever Locking facility Air filters Options Stem extension Gasket completely of stainless steel or laminated PTFE Cavity-free bearing Special materials Low-temperature version High-temperature version
