Lubricated vacuum ejector VGS™2010two-stagesingle-stageindustrial
Add to favorites
Compare this product
Characteristics
- Lubrication
- lubricated
- Number of stages
- two-stage, single-stage
- Applications
- industrial
- Ultimate vacuum
Min.: 0.79 bar
(11.46 psi)Max.: 0.91 bar
(13.2 psi)- Operating temperature
Min.: -10 °C
(14 °F)Max.: 80 °C
(176 °F)
Description
A product design where different suction cups are integrated with vacuum cartridges based on the patented COAX® technology. The “vacuum gripper” makes selection, sizing and installation of a vacuum system easier. With a VGS™ you will enjoy the benefits of a more cost-efficient and reliable decentralized vacuum system.
Features
Patented COAX® technology.
Compatible with any suction cup with G1/8" male fitting. Suction cup ordered separately.
Available with a two-stage COAX® cartridge MICRO. Configurable to your specific needs. Choose Bi for low feed pressure, Si for high vacuum flow, Xi for extra vacuum and Ti at 0.4/0.6 MPa for extra capacity/dirt tolerance.
