3-blade impeller HTPG4®

for agitatorsaxial-flow

MODEL : HTPG4® APPLICATIONS : The axial flow impeller “par excellence” The design of the Pierre Guerin patented impeller HTPG4® originated from work focusing on two hydrodynamic mixing objectives, essential for the mixing of any fragile or shear sensitive product: • to minimise the shear effect • to obtain maximum efficiency ratio: circulation rate / power consumption, in order to optimise the production cycle-time and minimize the electrical consumption. Our mixing expertise combining the understanding of the client processes together with the HTPG4® performance brings the best solution to your mixing requirements. Flow efficiency of the HTPG4 impeller is unique. • the minimum shear effect generated by the impeller allows for an optimum preservation of the product structure and integrity (fat matter, proteins, cells, etc.) • the impeller design induces an oriented flux that avoids any radial leak and generates two distinct upward and downward flows. Circulation rate and thus mixing time are enhanced. • consumed power is minimized due to the very low Power Number (0.67) of the HTPG4 impeller. DESCRIPTION : Three-bladed impeller agitator utilized for the following operations: homogeneous holding, mixing and re-suspension of solids, dissolution of powders into liquids, heat transfer. APPLICATIONS : Milk maturation and standardisation, milk fermentation, curd breaking, crystallization, preparation of sugar syrups, cooked meals, process eggs, brine, assembly of wines, cell cultivation (biotechnology), etc.
