PITjog manually operated control device 3 built-in pushbuttons, connection via 10-pin coiled cable with open end.
General data
Approval - CE
Self-monitored - no
Technical data
Electrical data
Supply voltage (V) - 24
24
Type of supply voltage U1 - AC/DC
Push button
Number, pushbutton - 3
Relay outputs
Voltage DC1 safety cont. - 24
Environmental data
Ambient temperature - -10
55
Protection type, housing -
Mechanical data
Length cable - 5
Material of cable insulation 1 - PUR
Conductor cross section - 0.14
0.14
Housing material - PC-ABS-Blend UL 94V0
Height dimension - 341
Width dimension - 75
Depth dimension - 60
Net weight - 837
Gross weight - 951
