Analog I/O module PSSu E F AI I-R

Analog I/O module - PSSu E F AI I-R - PILZ
Analog I/O module - PSSu E F AI I-R - PILZ
Add to favorites
Compare this product


Characteristics

Signal type
analog

Description

PSSu, electronic module, failsafe, analogue inputs and outputs, 1 input,0 - 25.59 mA, dual-pole, differential input, resolution 12 Bit, potential-free, for railway applications. General data Approval - CE UKCA EAC (Eurasian) TÜV Application range - Fail-safe Technical data Analog inputs Number of analogue inputs - 1 Type of analogue inputs - Strom Signal range analog input - 0 .. 25,59375 mA Type of input filter - RC-Filter Resolution of analogue inputs - 12 Conversion method analog i/p - sukzessive Approximation Pot. isolation analog inp./ - ja Inputs Potential isolation inputs - ja Environmental data App. site standard1 railway - EN 50125-3 App. site to standard1 railway - Gleisbereich (1m - 3m) App. site standard2 railway - EN 61373 App. site to standard2 railway - Kategorie 1, Klasse A + B Climatic suitability to ... - EN 50125-1 EN 60068-2-2 EN 60068-2-1 EN 50155 EN 60068-2-14 EN 50125-3 Ambient temperature standard - EN 50155 Ambient temperature - -40 Standard 2 for ambient temp. - EN 50125-1 Ambient temp. to standard 2 - -40 ... +70 °C Standard 3 for ambient temp. - EN 50125-3 Ambient temp. to standard 3 - -40 ... +70 °C
