External cylindrical grinding machine HOD4-SPworkpieceautomatic2-axis
Add to favorites
Compare this product
Characteristics
- Type
- external cylindrical
- Applications
- workpiece
- Control type
- automatic
- Number of axes
- 2-axis
- Spindle speed
Min.: 0 rpm
(0 rad.min-1)Max.: 12,000 rpm
(75,398 rad.min-1)- Power
1 ch
(1 hp)- X travel
90 mm
(3.54 in)- Y travel
50 mm
(1.97 in)
Description
Workpiece is clamped a 4-inch-three-jaw chuck.
●Workpiece diameter can be clamped from ∅1mm to ∅95mm.
●X, Y axis feeds are manually operated.
●The grinding wheel spindle running is controlled through a frequency inverter.
●Variable speed change for the wheel spindle and the work spindle.
●Double "V" slideways are hardened. Slide surfaces are precisely ground, coated with Turcite-B and hand scrapping
