High-power power transmission belt PIX-Valiant®-XSVrubberagricultural
Add to favorites
Compare this product
Characteristics
- Type
- V
- Material
- rubber
- Product applications
- agricultural, for harvesters
- Other characteristics
- high-power, high wear resistance, wrapped, oil-resistant, heat-resistant
- Length
Max.: 196 in
Min.: 46 in
- Width
13 mm, 17 mm, 22 mm
(0.512 in, 0.669 in, 0.866 in)- Thickness
8 mm, 10 mm, 11 mm
(0.31 in, 0.39 in, 0.43 in)- Temperature
Max.: 100 °C
(212 °F)Min.: -25 °C
(-13 °F)
Description
Features
- High power transmission capacity as compared to standard Belts
- High tensile strength
- Special design in wrap construction to facilitate operation on small pulley diameter with an acute reverse bend
- Extended service life
- Extended temperature range: -25°C to + 100°C
Constructional Details
1.Specially designed woven fabric to enhance the flexibility, adhesion as well as high wear resistance properties.
2.Specially treated polyester cord.
3.Fibre-loaded high modulus base compound facilitates enhanced power transmission.
4.Multi-layer fabric at the bottom to resist the premature crack formation.
Applications
Rice harvesters, planters, etc.
