Banded power transmission belt PIX-DuraBand®-XSribbedVrubber
Add to favorites
Compare this product
Characteristics
- Type
- ribbed, V
- Material
- rubber
- Product applications
- for heavy-duty applications, agricultural, for pump, for presses, for generator sets, for harvesters, for rotors, for hot rolling mills
- Sector
- industrial, for the automotive industry, for the food industry, medical
- Other characteristics
- anti-static, high-performance, high-power, wrapped, for heavy loads, aramide-corded, banded, oil-resistant, heat-resistant, ATEX
- Length
Max.: 23,629 mm
(930.28 in)Min.: 838 mm
(32.99 in)- Width
Max.: 25.4 mm
(1 in)Min.: 13 mm
(0.512 in)- Thickness
Max.: 25 mm
(0.98 in)Min.: 10.5 mm
(0.41 in)- Pitch
Max.: 28.6 mm
(1.126 in)Min.: 15.9 mm
(0.626 in)- Temperature
Max.: 80 °C
(176 °F)Min.: -30 °C
(-22 °F)
Description
Features
Enhanced power transmission capacity up to 25%, compared to standard Belts
Lesser number of Belts is required as compared to multiple single-belt drive system
Extended service life
Top curvature provides superior adhesion and accelerates heat dissipation rate
Controlled radial and lateral run-out facilitates smooth operation
Anti-static, oil and heat resistant
ATEX certified FRAS Belts are also available
Temperature range:-30°C to +80°C
Constructional Details
Special Curved top tie band design for better flexibility and heat resistance
High modulus - low shrinkage tension member embedded cushion rubber compound
High tenacity, low stretch specially treated polyester cord
Specially designed compression rubber gives stability to the Belt cross-section and supports the cord zone against deflection, under load condition
Wear-resistant, bias-cut neoprene rubberized polyester cotton fabric
